syringe filter

The HPLC Syringe Filter provides efficient filtration of samples in high-performance liquid chromatography (HPLC) applications. These filters are designed to remove particulate matter, contaminants, and debris from samples, ensuring clean and reliable results. With precise pore sizes and high flow rates, they enable rapid and efficient filtration without sample loss.

The syringe filters are designed for easy and efficient filtration of liquids and gases. They feature a syringe-like structure with an inlet and outlet, allowing for direct attachment to a syringe or other fluid delivery systems. The filters remove particulates, microorganisms, and unwanted substances, ensuring clean and clarified samples for analysis.

The 0.22um 0.45um Lab Use Reusable Syringe Filter With Printing finds application in diverse laboratory settings. It is suitable for pharmaceutical research, biotechnology, environmental analysis, food testing, and other scientific research fields.

A syringe filter is a quick, convenient and reliable filter tool used routinely in the laboratory. Because they don’t need to change the membrane and filter cleaning, it’s eliminating the complex and time-consuming preparation.

In HPLC analysis, the particle size of the chromatographic column packing is small and it is easy to be blocked by impurity particles. Therefore, samples and solvents need to be filtered in advance to remove particulate contaminants and protect the instrument. Ion chromatography, which is commonly used in environmental analysis, also requires that no inorganic pollutants be introduced in sample pretreatment.

PVDF syringe filters are made of hydrophilic PVDF membrane and a polypropylene overmold housing. Available in 13 mm and 25 mm diameters and 0.22 μm and 0.45 μm pore sizes.

In HPLC analysis, the particle size of the chromatographic column packing is small and easily blocked by contaminant particles. Therefore, samples and solvents must be pre-filtered to remove particulate contaminants and protect the instrument.

Sterile syringe filters are syringe-operated filters for the clarification of aqueous solutions (column eluate, tissue culture additives, HPLC samples, etc

Syringe filter is a small, disposable device that is commonly used in laboratory settings to filter or clarify fluids. It is designed to be attached to the end of a syringe and acts as a barrier that removes particles and contaminants from the fluid as it is forced through the filter.
Syringe filters typically consist of a plastic housing with a membrane filter inside. The housing has a female luer lock or luer slip connection that allows it to be securely attached to the syringe. The membrane filter, which is the key component, is made of a porous material that allows the fluid to pass through while retaining particles and contaminants above a certain size.

 In HPLC analysis and IC analysis, syringe filters can be used to filter sample solutions, which is an important step in sample pretreatment.

Chromatography commonly used in environmental analysis requires that no inorganic contaminants be introduced during sample pretreatment. In HPLC analysis and IC analysis, syringe filters can be used to filter sample solutions, which is an important step in sample pretreatment.

Syringe filter is a disposable device used in laboratory settings to filter small volumes of liquid samples. It is commonly utilized to remove particulate matter and microorganisms from solutions before analysis or to protect sensitive instruments from contamination.
Syringe filters consist of a plastic housing with a membrane filter at one end and a female luer lock or luer slip connection at the other end. The filter membrane is typically made of materials such as nylon, polyethersulfone (PES), polytetrafluoroethylene (PTFE), or cellulose acetate.

Aijiren disposable MCE syringe filter units are designed to provide clear filtration of aqueous and organic solutions from small volumes up to 100 mL.
MCE syringe filters are made from mixed cellulose ester (MCE) membrane and polypropylene overmolded housing.

PP housing membrane syringe filter refers to a syringe filter wif a housing made of polypropylene (PP).

Polypropylene is a commonly used material for syringe filter housings due to its chemical compatibility, low extractables, and resistance to a wide range of solvents. PP housings provide structural support to teh filter membrane and help maintain its integrity during filtration.
These syringe filters find applications in various fields such as pharmaceuticals, biotechnology, environmental analysis, food and beverage testing, and research laboratories where precise filtration is required to ensure sample purity and integrity.

Disposable non-sterile syringe filter devices are designed to provide fast and efficient filtration, premium quality and economy. The membrane could be PTEF, PVDF, PES, Nylon, MES, PP, CA, and can be suitable for different situations.

Aijiren disposable PVDF syringe filter devices are designed to provide clear filterate of aqueous and organic solutionsfrom small volumes up to 100 mL.
PVDF syringe filters are made of hydrophilic PVDF membrane and a polypropylene overmold housing.

Disposable syringe filter devices are designed to provide fast and efficient filtration, premium quality and economy. The membrane could be PTEF, PVDF, PES, Nylon, MES, PP, CA, and can be suitable for different situations.

A disposable HPLC (High-Performance Liquid Chromatography) syringe filter is a specialized type of syringe filter designed specifically for HPLC applications. HPLC is a widely used analytical technique in chemistry and biochemistry for separating, identifying, and quantifying components in a liquid sample. These filters ensure that the sample is free from particles that could clog the column or interfere with the analysis

13 mm 0.22 um syringe filters come in various sizes, pore sizes, and materials to suit different applications. It is important to select the appropriate filter based on the type of sample, the desired filtration efficiency, and the compatibility of the filter material with the solvent or solution being filtered.Syringe filters can remove particulate matter, debris, aggregates, colloids, bacteria, and other contaminants that may interfere with the analysis.

13/25 mm 0.22/0.45 um syringe filters are used to achieve a cleaner and purer liquid sample for various laboratory applications. They are particularly useful in sample preparation for analytical techniques such as chromatography or spectroscopy, where removing impurities is crucial for accurate results.The filtered liquid passes through the membrane and collects in a separate container, while the impurities are retained by the filter.

These vials are commonly used in fields such as pharmaceuticals, biotechnology, chemistry, clinical diagnostics, and environmental analysis. They are compatible with automated systems, including autosamplers, making them suitable for high-throughput analysis and efficient sample handling.This design ensures a tight seal to prevent leakage, sample evaporation, or contamination.

0.45 um 25 mm syringe filters are commonly used in laboratory settings, particularly in analytical chemistry, to prepare samples for analysis or to clarify solutions before further processing. They are designed to effectively trap and remove particles, contaminants, or unwanted substances from the liquid being filtered. The filters are available in various pore sizes, allowing for the selection of a filter dat is appropriate for the specific application and the desired level of filtration.

13/25 mm,0.22 um syringe filter is a small, disposable filter device that is used to remove impurities or particles from a liquid sample. It consists of a plastic housing with a membrane filter at one end and a female Luer lock or slip tip at the other end, which allows it to be attached to the end of a syringe.Syringe filters are convenient, cost-effective, and widely used in laboratory applications where small volumes of liquid need to be filtered quickly and efficiently.

Aijiren¡¯s syringe filter has many different types of membranes. Aijiren can also sell membranes separately. Different reagents need to choose membranes of different materials to avoid the reaction between the membrane and the reagents and affect the experimental results. Aijiren usually recommends customers to choose PTFE, because PTFE is extremely inert and suitable for most reagents.

Aijiren recommends that each syringe filter be used only about 10 times. If there are too many impurities in the reagent, the pore size of the syringe filter will be blocked and the filtration task cannot be completed. The Syringe filter provided by Aijiren has a favorable price and good quality. It is very suitable to change to a new Syringe filter to continue filtering after using it several times.

The PTFE Syringe Filter in the picture has an aperture of 0.22, an outer diameter of 25mm, and a purple color. Aijiren also offers many other colors of Syringe Filter, such as yellow, pink, blue, green, etc. Customers can choose according to their preferences . The Syringe Filter produced by Aijiren can be equipped with many different types of filter membranes, which can be selected according to the reagents that customers need to filter.

Aijiren’s Syringe Filter is usually 100pcs/pack. Generally speaking, it is packaged in a plastic box. If the Syringe Filter is packaged in a plastic box, the Syringe Filters will not squeeze each other. The recommended minimum order quantity is 30 boxes.

Aijiren PVDF filters are high defined pore structure, low nonspecific binding, compatible with organic and aqueous solvents. Please note that Hydrophilic PVDF syringe filters are not compatible with majority of strong acids and caustic solutions, such as dimethyl sulfoxide, dimethylformamide (DMF), acetone, ketones, esters, and ethers.

Syringe filters are made of many different types of materials. Various materials, diameters, pore sizes, and sterile and non-sterile options are on our list. These syringe filters provide excellent microfiltration performance for HPLC, water treatment, environment, biotechnology, beverage, food, pharmaceutical and other related fields.

As an important tool for filtering reagents, the Nylon syringe filter plays a very important role, especially in chromatographic consumables. A slightly larger impurity particle in the reagent may cause clogging of the instrument.

The nylon membrane used in the syringe filter has high mechanical strength, chemical stability, can be tolerated by most organic solvents, has very low extractables, has good thermal stability and natural hydrophilicity, and is filtered by most aqueous solutions characteristic.

PTFE is hydrophobic and needs to be pre-wetted before being used with aqueous solvents. Used for: corrosive solvents, strong acids, alcohols, alkalis, aromatic hydrocarbons. Not suitable for: water-based samples.

In chromatographic experiments, the sample is placed on the chromatographic column for analysis after the sampler is injected. However, the inner core of the sampler and the chromatographic column is relatively thin. If there are large particles in the sample, it may cause the device to block , Need to use Syringe Filter for preliminary sample filtration treatment.

PTFE Syringe Filter is resistant to almost all corrosive chemicals, which makes PTFE syringe filters an ideal choice. However, the disadvantage of natural hydrophobic PTFE is that after many chemicals are diluted with water, the aqueous solution cannot pass through. Need to be wetted with water in advance.

The PTFE syringe filter is a general-purpose filter, and it is also Aijiren’s higher-selling syringe filter. PTFE is inert to many aggressive solvents and strong acids and alkalis. These syringe filters can also be exposed to high temperatures and are an excellent choice for HPLC sample preparation. Aijiren offers PTFE syringe filters in a hydrophobic state.

Aijiren’s expert staff is available via live chat and email to help you decide on the best membrane filter for your needs. Email us, and our helpful customer representatives will respond promptly¡ªin just one business day or sooner. And if you still need help deciding on the right product, we¡¯ll ship you a sample to ensure you receive the best membrane filter for your needs.

Features of the syringe filter: Luer lock inlet provides a sealed syringe connection, with various filter types, porosities and diameters. Color coding is easy to identify. Rugged polypropylene shell. Can be autoclaved to 121℃ for 15 minutes. The quantity exceeds the minimum order quantity to save more.

MCE Syringe Filter is generally used to filter neutral or partial neutral aqueous solutions, and can be used as experimental sample clarification filtration, liquid chromatography injection filtration and so on. Not suitable for filtering organic solvents and strong acid and alkali solutions. This filter is for one-time use, filtering about 10 ml at a time (specifically, there is a big difference according to the impurities of the filtered liquid), and the filter membrane cannot be disassembled. 0.45¦Ìm can remove conventional impurities and some bacteria visible to the naked eye. Generally used in conjunction with the syringe.

Aijiren Syringe Filters is a comprehensive range of non-sterile disposable syringe filters for reliable sample preparation. Reproducible membrane quality and automated manufacturing processes ensure particulates are removed from each and every sample, extending analytical column lifetime and minimising injection port or valve damage.

Polypropylene is compatible with acetone, ethyl acetate, methanol, isobutanol, methanol and methyl ethyl ketone. Polypropylene is incompatible with cyclohexane, ether, dichlorobenzene, pentane, methylene chloride and trichlorobenzene. It is recommended to use gas, disinfectant or autoclave to sterilize products made of polypropylene. The maximum operating temperature is 135¡ãC.

Nylon membrane has high strong mechanical strength, chemical stability, can be tolerated by most organic solvents, extremely low in extractables, good thermal stability (up to 50¡ãC), natural hydrophilic and the majority of water solution filter characteristics. It more often applied to the common organic solvent HPLC mobile phase filtering.

MCE features: relatively uniform pore size, high porosity, no media shedding, thin texture, low resistance, fast filtration rate, and minimal adsorption.
The main purpose of MCE: to filter out the particles and bacteria of liquid medicine, gas, oil, beverages, sprinkles, electronic instruments, etc., and can also be used for the detection of particles and bacteria.

Selected PES syringe filters provide a cleaner sample extract by removing interfering materials and fine particles down to the rated pore size. Performing a syringe filtration step before chromatographic injection helps ensure more consistent and reliable results, and helps protect delicate instruments and extend column life.

PTFE: is perfect for the filtration of gaseous or organic solvent-based samples and highly corrosive substances. Hydrophobic so provides chemical resistance to aggressive media and excellent temperature stability allowing an extended sampling range. If used with aqueous samples, the membrane usually requires pre-wetting (normally by using a small amount of alcohol). Can also be used to prevent moisture passing through air vents. pH range ~1-14.

The hydrophobic PTFE syringe filter membrane is made of hydrophobic polytetrafluoroethylene. It filters organic solvents, aqueous solutions and gases that are chemically corrosive, and can withstand most strong acid and alkaline solutions. Product application: Used for the clarification and filtration of strong acids and alkalis, the filtration of high-temperature liquids and special chemical reagents, and the clarification and filtration of air or various gases.

Your benefits when using Aijiren syringe filters£ºDifferent membrane types to meet multiple filtration needs. Low content of extractable compounds. Fast flow geometry for easy filtration. Low hold-up volume for maximum filtrate recovery. HPLC certified

Mainly used in the following aspects: HPLC sample preparation; conventional QC analysis; content uniformity; removal of protein precipitates; dissolution test; food analysis; biofuel analysis; environmental samples

Convenient and Easy to Use£ºPES Syringe filters can be sterilized by autoclave at 125¡ãC for 15 minutes£¬Enhanced Luer Lock inlet prevents leakage; outlet fitting is a standard size male Luer-slip fitting for ease of filtrate collection, Come in bulk packs of 100 and not individually wrapped

The PTFE syringe filter is tritium-free and has a two-way membrane support and Luer lock inlet/outlet and a safe and suitable syringe. The membrane type and pore size are printed on each filter for easy identification. All Aijiren syringe filters are 100% integrity tested and comply with ISO 9002 standards. The sterilizing filter is sterilized with gamma rays. And detect no pyrogen, no cytotoxicity.

The MCE membrane filter provides researchers with the lowest combined filter. Due to their extremely low binding characteristics, these filters provide higher throughput than competing products and reduce filter replacement when filtering protein solutions.

The advantages of Syringe Filter: The low extractable membrane and shell ensure that no filter contaminants are added to your samples. Aijiren performs performance tests under actual HPLC conditions. The integrated 1mm borosilicate glass prefilter (30mm device) ensures higher confidence in samples with high solids content.

PES syringe filter is hydrophilic in nature, and has low protein binding, high flow rate and excellent chemical stability. In addition, it also contributes to oxidation stability, high heat and low concentration of extractable elements.

Aijiren¡¯s PP syringe filter uses a hydrophobic polypropylene membrane, which has stable physical and chemical properties, good compatibility, low protein adsorption, and is suitable for filtration of aqueous solutions and most solvents. Commonly used to filter biological samples, solvents, deionized water and reduce biological load, the hydrophobic PP filter membrane is particularly good for gas filtration. The product was sterilized by dry heat at 121¡ãC for 15 minutes.

The reinforcement ring can provide greater strength to the shell to prevent leakage and bursting (30mm product pressure is rated at 120 psi). The shell is made of solvent-resistant, low-extraction polypropylene resin, specifically selected for wide compatibility with common HPLC sample matrices. The solution can be filtered at temperatures up to 100¡ãC, which is convenient and easy to use.

The special color contrast provided on the surface of the MCE film helps to detect particles and minimize eye strain. It is ideal for the recovery and retention of bacteria in colony counting and sterility testing, as well as water/wastewater analysis and other microbiological tests.

Although Aijiren has attractive prices, the focus is still on quality. The membrane materials are provided by the most famous people in the industry, and in the ISO9000 certified production process, the latest manufacturing technology is used, and the production is carried out under the highest standard under certified clean room conditions to ensure high quality and stable products. . All syringe filters are HPLC certified.

Aijiren PP syringe filter
Product Model: 25mm,0.22um Sterilization Independent Packaging
Application: sterilize and filter the aqueous solution
Operating temperature: 45¡ãC
Inlet pressure: bar (psi): 5.2 (75)
Wettability: hydrophilic
Filter membrane diameter: 25mm
Membrane aperture: 0.22um

Nylon has excellent flow characteristics, extremely low extractable level and mechanical stability, and can provide the best combination of physical parameters to meet the most stringent analysis requirements of 13mm, 25mm and 33mm diameters. Nylon’s natural hydrophilicity, high protein binding capacity and high dirt adsorption capacity are natural advantages.

The shell of PTFE Syringe Filter is made of polypropylene (PP) with excellent chemical stability. It is made of different colors, which is convenient for users to distinguish products of different materials and avoid confusion. The filter membrane adopts imported high-performance filter membrane with stable product quality and good reproducibility. It is an ideal choice for laboratory filtration of samples. The standard interface is convenient to connect to various syringes, and it can also be directly connected to the needle of the 7725 valve, and the sample can be injected directly after filtration.

PTFE is a hydrophobic membrane that is chemically resistant to almost all solvents. It can be used with corrosive media, such as strong acids, alcohols, alkalis, and aromatics. The unit is readily available, allowing simple, fast and reliable HPLC or GC analysis of ultra-clean small-volume samples. PTFE filters can also be used to prevent moisture from passing through the vents.

Cellulose Acetate Syringe Filter Surfactant-free membrane for cleanliness in downstream applications, Filter type printed on the filter for ease of identification, Convenient, larger pack sizes,Gamma sterilised.

Features of MCE: uniform pore size, thin texture, low flow resistance, high filtration speed, low absorption, all items are quality tests for filter efficacy and housing integrity. The housing is pressure tested and can withstand pressures up to 75 psig (5.0 bar). Some filters are individually packaged aseptic packaging, certified, RNase, DNase and DNA free, and non-pyrogenic.

Polyethersulfone (PES): Hydrophilic, stable in low pH, have low levels of extractables, and exhibit low protein binding, making them suitable for many aqueous and organic solvents. PES membranes allow higher liquid flow than PTFE. Temperature resistant. pH range ~3-14 (sometimes quoted as 1-14).

Due to the high hydrophobicity of the PVDF membrane, it needs to be soaked in an appropriate solution such as ethanol before use to achieve the purpose of activation and make the membrane easier to bind proteins. This product is compatible with many dyes, such as Ponceau-S red, Coomassie brilliantblue, Sypro ruby, Transillumination, Toluidine blue, CPTS, Colloidal gold, India inkAmido black. Among them, after dyeing with dyes such as Ponceau and CPTS, the dyes can be washed off and the film can be used for further analysis; while dyes such as Coomassie Brilliant Blue, India ink, and amide black are irreversible, the film cannot be used after dyeing. For further analysis.

PTFE (polytetrafluoroethylene) performance: suitable for water system and various organic solvents, resistant to all solvents, low solubility. It has the characteristics of air permeability and water impermeability, large air flux, high particle retention rate, good temperature resistance, resistance to strong acids, alkalis, organic solvents and oxidants, resistance to aging, non-stickiness, non-flammability, non-toxicity, and biocompatibility. Its related products are widely used in chemical, pharmaceutical, environmental protection, electronics, food, energy and other fields

PTFE Syringe Filters are universal filters that are inert to a wide variety of aggressive solvents and strong acids and bases. These syringe filters can also be exposed to high temperatures and are an excellent choice for HPLC sample preparation. We offer PTFE syringe filters in both their hydrophobic and hydrophilic states.

Disposable syringe filters are widely used in labs for quick and efficient filtering, material purification or even sterilization for solutions <250mL, to avoid setting ups of Buchner filters or similar.

Membrane: ?ICP Certified PES (Polyethersulfone)??
Use with: ?Strong bases, alcohols, proteins, peptides
Don¡¯t use with: ?acids, ketones, esters, halogenated or aromatic hydrocarbons.
Sterilization: ?Syringe filters can be sterilized by autoclave at 125¡ã for 15 minutes.
Applications: ?Ion chromatography, tissue culture filtration, filtration of proteins and nucleic acids, high-temperature liquids.

Feature and benefits: 0.2 ¦Ìm hydrophobic air filters are excellent industrial air filter media. Testable by water break through (WBT) test or bubble point testing.Passes USP Class VI biosafety tests for plastics. Manufactured in clean room facilities. Range of filtration areas from 4¨C2000 cm2 to support filtration volumes as small as one liter and as large as a large tank vessel

Cellulose acetate is a very low protein binding membrane that is ideal for aqueous based samples and biological samples. It is a lower protein binder than either polyethersulphone or PVDF membranes, but has a lower chemical resistance than regenerated cellulose (RC). CA is a strong membrane mechanically and hydrophilic.

The syringe filter has the following characteristics:
1. Convenient, readily available, easy to operate, economical and practical.
2. Reliable bacteria retention efficiency ensures the filtering and sterilization effect.
3. Larger effective membrane filtration area: 1.09cm2.
4. High flow rate, high throughput, dead volume no more than 10¦Ìl.
5. Very low protein adsorption.
6. Pass HPLC dissolution test.

In addition to HPLC, syringe filters have a multitude of other applications. A syringe filter adds a few minutes and a minimal expense to your testing process, but you will see a big return on your investment. Small volume venting£¬HPLC sample preparation£¬Removal of protein precipitates£¬Routine QC analysis£¬Dissolution testing.

Sample preparation for high-throughput Ultra High Performance Liquid Chromatography (UHPLC)/High Performance Liquid Chromatography (HPLC) analysis can be time consuming when using multiple consumables such as a syringe, syringe filter, sample vial, cap, and septum. Aijiren HPLC filters result in faster sample preparation than the normal syringe filter method.

They are also very useful in the protection of vacuum pump pipelines and have the qualities of high absorption and retention capacity. Due to their advantages, these syringes can be used in laboratory situations as well as industrial applications.

PVDF syringe filters have excellent chemical compatibility, mechanical strength and low extractability. In these filters, the maximum allowable housing pressure is 150 psi. It improves the filtering speed. These filters have high temperature resistance due to their materials. They have excellent flow rate and temperature stability.

Polyethersulfone filter has the characteristics of high flow rate, low extraction loss, and higher mechanical resistance than cellulose membrane. It is suitable for biological, pharmaceutical, sterilization and filtration. The membrane is sealed in the polymer shell without using any adhesive. Each unit is ETO or gamma ray sterilized and guaranteed to be pyrogene-free.

Compressed sterile air filters can be used to create clean rooms free of bacteria and other harmful particles for people with compromised immune systems. Each air supply pump is also equipped with a sterile air filter to ensure the delivery of pollution-free air. These air filters are usually sterilized by gamma rays and packaged separately.

The use of PTFE syringe filters can be used for corrosive solvents, aerosol sampling, degassing agents, exhaust applications and organic-based HPLC filtration. The syringe filter has a variety of different filter covers, and has a wide range of chemical compatibility, and has strong chemical stability and inertia.

Designed to be compatible for the use on all common automated filtration systems, Standard syringe filters are color coded. Aijiren syringe filters are labeled for method validation and certification. All syringe filters are autoclavable (121 ¡ãC and 1.1 bar for 30 min).

Another way to determine the micron size of columns, 0.45 um for >3 um, and 0.22 um for <3um. 0.45 um membranes are typically used for general filtration and particle removal while 0.2/0.22um membranes, or sterilizing-grade membranes, are most commonly used for solution sterilization (bacteria removal).

Aijiren’s products enable pharmaceutical companies to increase productivity. Syringe filters and vials reduce HPLC sample preparation time and consumables usage, and track-etched and membranes are also vital to extruding liposomes for encasing and targeting drugs.
